OEM CROSS REFERENCE
| Pall | FMC |
|---|---|
| HC8300E6039H | F8300-39W60B |
ELEMENT RATING
| Test Containment | |
| Test Oil | |
| Terminal Pressure |
| Pall | Micron | FMC | Average Filter, Ratio |
|---|---|---|---|
| 60 | W60 | 60 Micron Absolute | |
| 74 | W74 | 74 Micron Absolute | |
| Element Collapse Press | ANSI B93.25/ISO 2941 | 150 PSID ( 10.3 bar ) Minimum |
| Dirt Holding Capacity | ANSI B93.31/ISO 4572 | NA |
| Flow Fatigue Resistance | ANSI B93.24/ISO 3724 | NA |
| Fluid Compatibility | ANSI B93.23/ISO 2943 |
Compatible with Petroleum Oils 250 F (121 C) Water based fluids, Water Glycol 200 F ( 93 Phosphate Esters require Viton A "O" Rings |
| Element Integrity | ANSI B93.22 | NA |
| Operating Temperature | -20 + 250 F (-29 + 121 C) |
ELEMENT DATA
| Filtration Area | 5300 SQ.IN. (3.42 M2) |
| Element Type | Cleanable |
| Direction of Flow | Out/In |
| Bond Material | Epoxy |
| Hardware | Plated Steel |
| Element QTY/CTN | 1 One |
| Element WT /CTN | 16 LBS (7.26 kg) |
| Element VOL/CTN | 1770 CU.IN. (0.030 m3) |
