Filtermart™ PLEATED PAPER ELEMENT

Add To Cart

FMC #01-0499

Price: TBD

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Liquid Filters/Pleated Paper/General Purpose

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	10.00 NOMINAL
  Beta Rating:
  Collapse Pressure Rating:
  Maximum Temperature:
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	3.00 IN (76.20 MM)
  (C) Inner Diameter, Top:	0.44 IN (11.18 MM)
  (D) Inner Diameter, Bottom:	1.19 IN (30.23 MM)
  (E) Length:	4.38 IN (30.23 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:
  Type of Endcap:	PLATED STEEL
  Center Tube:	PLATED STEEL
  Type of Media:	PAPER
  Filter Area:	SQ.IN.
  Plating:	ELECTROTIN PLATED
  Outer Jacket:	YES
  Configuration:	SINGLE OPEN / BOLT

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	6.00 LB (2.72 KG)
