All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Liquid Filters/Pleated Synthetic/Microglass
| Micron Rating: | 10.00 ABSOLUTE |
| Beta Rating: | B10=200 |
| Collapse Pressure Rating: | 75 PSID |
| Maximum Temperature: | 175 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 50 PSID |
| (A) Outer Diameter, Top: | 4.17 IN (105.92 MM) |
| (B) Outer Diameter, Bottom: | 4.17 IN (105.92 MM) |
| (C) Inner Diameter, Top: | 0.35 IN (8.89 MM) |
| (D) Inner Diameter, Bottom: | 2.84 IN (72.14 MM) |
| (E) Length: | 7.48 IN (72.14 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | BUNA-N |
| Type of Adhesive: | EPOXY |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | MICROGLASS |
| Filter Area: | SQ.IN. |
| Plating: | ZINC PLATED |
| Outer Jacket: | YES |
| Configuration: | SINGLE OPEN / BOLT |
| Number per Carton: | 1 |
| Carton Weight: | 3.00 LB (1.36 KG) |
