Filtermart™ PLEATED MICROGLASS ELEMENT

Add To Cart

FMC #05-1286

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*10 per carton

Industrial Filters/Liquid Filters/Pleated Synthetic/Microglass

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.30 ABSOLUTE
  Beta Rating:	N/A
  Collapse Pressure Rating:	15 PSID
  Maximum Temperature:	275 F
  Direction of Flow:	INSIDE-->OUT
  Recommended Changeout Differential Pressure:	50 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	6.00 IN (152.40 MM)
  (B) Outer Diameter, Bottom:	6.00 IN (152.40 MM)
  (C) Inner Diameter, Top:	4.20 IN (106.68 MM)
  (D) Inner Diameter, Bottom:	4.20 IN (106.68 MM)
  (E) Length:	40.00 IN (106.68 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	N/A
  Type of Endcap:	PLATED STEEL
  Center Tube:	TIN PLATED
  Type of Media:	MICROGLASS
  Filter Area:	SQ.IN.
  Plating:	ELECTROGALVANIZED
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	10
  Carton Weight:	12.00 LB (5.44 KG)
