All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Wire Filters/Pleated
Micron Rating: | 10.00 94% NOM |
Beta Rating: | N/A |
Collapse Pressure Rating: | N/A |
Maximum Temperature: | N/A |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 25 PSID |
(A) Outer Diameter, Top: | 12.13 IN (308.10 MM) |
(B) Outer Diameter, Bottom: | 12.13 IN (308.10 MM) |
(C) Inner Diameter, Top: | 8.81 IN (223.77 MM) |
(D) Inner Diameter, Bottom: | 8.81 IN (223.77 MM) |
(E) Length: | 12.25 IN (223.77 MM) |
(F) Thread: | NONE |
Handle: | NONE |
Seal Material: | MOLDED |
Type of Adhesive: | N/A |
Type of Endcap: | PLASTISOL |
Center Tube: | STEEL |
Type of Media: | 304 SS WIRE |
Filter Area: | N/A |
Plating: | N/A |
Outer Jacket: | NONE |
Configuration: | DOUBLE OPEN END |
Number per Carton: | 1 |
Carton Weight: | 6.00 LB (2.72 KG) |
