All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Wire Filters/Pleated
| Micron Rating: | 149.00 NOMINAL |
| Beta Rating: | |
| Collapse Pressure Rating: | 450 PSID |
| Maximum Temperature: | 400 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 25 PSID |
| (A) Outer Diameter, Top: | 1.75 IN (44.45 MM) |
| (B) Outer Diameter, Bottom: | 1.75 IN (44.45 MM) |
| (C) Inner Diameter, Top: | 0.88 IN (22.35 MM) |
| (E) Length: | 6.20 IN (0.00 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | VITON |
| Type of Adhesive: | EPOXY |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | 304 SS WIRE |
| Filter Area: | SQ.IN. |
| Plating: | ZINC PLATED |
| Outer Jacket: | NONE |
| Configuration: | SINGLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 1.60 LB (0.73 KG) |
