All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Wire Filters/Pleated
| Micron Rating: | 25.00 ABSOLUTE |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | 225 F |
| Direction of Flow: | |
| Recommended Changeout Differential Pressure: | 0 PSID |
| (A) Outer Diameter, Top: | 6.20 IN (157.48 MM) |
| (B) Outer Diameter, Bottom: | 6.20 IN (157.48 MM) |
| (C) Inner Diameter, Top: | 3.69 IN (93.73 MM) |
| (D) Inner Diameter, Bottom: | 3.68 IN (93.47 MM) |
| (E) Length: | 15.66 IN (93.47 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | BUNA-N |
| Type of Adhesive: | |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | WIRE MESH |
| Filter Area: | |
| Plating: | |
| Outer Jacket: | NONE |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 9.00 LB (4.08 KG) |
