Filtermart™ DEPTH TYPE ELEMENT

Add To Cart

FMC #10-0155

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*7 per carton

Industrial Filters/Depth Filters/Natural or Synthetic Fiber

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	25.00 NOMINAL
  Beta Rating:	N/A
  Collapse Pressure Rating:	N/A
  Maximum Temperature:	275 F
  Direction of Flow:	OUTSIDE-->IN
  Recommended Changeout Differential Pressure:	25 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	4.38 IN (111.25 MM)
  (B) Outer Diameter, Bottom:	4.38 IN (111.25 MM)
  (C) Inner Diameter, Top:	1.06 IN (26.92 MM)
  (D) Inner Diameter, Bottom:	1.06 IN (26.92 MM)
  (E) Length:	31.50 IN (26.92 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	NONE
  Type of Adhesive:	N/A
  Type of Endcap:	N/A
  Center Tube:	CARBON STEEL
  Type of Media:	COTTON + WOOD
  Filter Area:	SQ.IN.
  Plating:	N/A
  Outer Jacket:	YES - SOCK
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	7
  Carton Weight:	31.00 LB (14.06 KG)
