All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Adsorption Filters/Activated Alumina
| Micron Rating: | 5.00 NOMINAL |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 100 PSID |
| Maximum Temperature: | 225 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 7.00 IN (177.80 MM) |
| (B) Outer Diameter, Bottom: | 7.00 IN (177.80 MM) |
| (C) Inner Diameter, Top: | 2.25 IN (57.15 MM) |
| (D) Inner Diameter, Bottom: | 2.25 IN (57.15 MM) |
| (E) Length: | 18.00 IN (57.15 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | VITON |
| Type of Adhesive: | EPOXY |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | SELEXSORB GT |
| Filter Area: | SQ.IN. |
| Plating: | ELECTROTIN PLATED |
| Outer Jacket: | YES - METAL |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 18.00 LB (8.16 KG) |
