All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
*6 per carton
Industrial Filters/Separator Filters/Liquid
| Micron Rating: | 150.00 ABSOLUTE |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 75 PSID |
| Maximum Temperature: | 225 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 6.00 IN (152.40 MM) |
| (B) Outer Diameter, Bottom: | 6.00 IN (152.40 MM) |
| (C) Inner Diameter, Top: | 3.50 IN (88.90 MM) |
| (D) Inner Diameter, Bottom: | 3.50 IN (88.90 MM) |
| (E) Length: | 8.38 IN (88.90 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | BUNA-N |
| Type of Adhesive: | EPOXY |
| Type of Endcap: | ALUMINUM |
| Center Tube: | ALUMINUM |
| Type of Media: | 304 SS/TEFLON |
| Filter Area: | SQ.IN. |
| Plating: | ANODIZED |
| Outer Jacket: | NONE - NONE |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 6 |
| Carton Weight: | 18.00 LB (8.16 KG) |
