Filtermart™ COMPRESSED AIR ELEMENT

Add To Cart

FMC #19-1021

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Coalescer Filters/Air/Borosilicate Glass

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.30
  Beta Rating:
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	180 F
  Direction of Flow:	INSIDE->OUT
  Recommended Changeout Differential Pressure:	15 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	2.53 IN (64.26 MM)
  (B) Outer Diameter, Bottom:	2.53 IN (64.26 MM)
  (C) Inner Diameter, Top:	1.34 IN (34.04 MM)
  (E) Length:	8.88 IN (0.00 MM)
  (F) Thread:

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	N/A
  Type of Endcap:	POLYPROPYLENE
  Center Tube:	POLYPROPYLENE
  Type of Media:	SYNTHETIC
  Filter Area:	SQ.IN.
  Plating:	NONE
  Outer Jacket:	NONE
  Configuration:	SINGLE OPEN END

• Packaging Specifications

  Number per Carton:

  1
