All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
| Micron Rating: | 0.00 ABSOLUTE |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 75 PSID |
| Maximum Temperature: | 180 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 22.25 IN (565.15 MM) |
| (B) Outer Diameter, Bottom: | 22.25 IN (565.15 MM) |
| (C) Inner Diameter, Top: | 17.63 IN (447.80 MM) |
| (E) Length: | 25.00 IN (0.00 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | POLYISOP |
| Type of Adhesive: | URETHANE |
| Type of Endcap: | ELECTRO GALVANIZED STEEL |
| Center Tube: | ELECTRO GALVANIZED STEEL |
| Type of Media: | 80/20 BLEND |
| Filter Area: | 220 SQ.FT. |
| Plating: | ELECTR-GALVANIZED |
| Outer Jacket: | YES - METAL |
| Configuration: | SINGLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 31.00 LB (14.06 KG) |
