All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
| Micron Rating: | 2.00 ABSOLUTE |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | 75 PSID |
| Maximum Temperature: | 180 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 9.23 IN (234.44 MM) |
| (B) Outer Diameter, Bottom: | 9.23 IN (234.44 MM) |
| (C) Inner Diameter, Top: | 5.84 IN (148.34 MM) |
| (D) Inner Diameter, Bottom: | 0.94 IN (23.88 MM) |
| (E) Length: | 22.30 IN (23.88 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | ISOPRENE |
| Type of Adhesive: | URETHANE |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | NANO |
| Filter Area: | 100 SQ.FT. |
| Plating: | ELECTR-GALVANIZED |
| Outer Jacket: | YES - METAL |
| Configuration: | SINGLE OPEN END /BH |
| Number per Carton: | 1 |
| Carton Weight: | 9.00 LB (4.08 KG) |
