All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
| Micron Rating: | 0.00 |
| Beta Rating: | |
| Collapse Pressure Rating: | N/A |
| Maximum Temperature: | 180 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 15.07 IN (382.78 MM) |
| (B) Outer Diameter, Bottom: | 15.07 IN (382.78 MM) |
| (C) Inner Diameter, Top: | 9.97 IN (253.24 MM) |
| (D) Inner Diameter, Bottom: | 9.97 IN (253.24 MM) |
| (E) Length: | 28.00 IN (253.24 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | |
| Type of Adhesive: | |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | |
| Type of Media: | 80/20 BLEND |
| Filter Area: | SQ.IN. |
| Plating: | |
| Outer Jacket: | NONE |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 16.70 LB (7.57 KG) |
