Filtermart™ DUST COLLECTOR ELEMENT

Add To Cart

FMC #21-2863

Price: TBD

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*Special Pricing – (limited qty), additional discounts do not apply

Industrial Filters/Air Filters/Dust Collector

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	10.00 NOMINAL
  Beta Rating:	N/A
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	150 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	9.25 IN (234.95 MM)
  (B) Outer Diameter, Bottom:	10.50 IN (266.70 MM)
  (C) Inner Diameter, Top:	5.75 IN (146.05 MM)
  (D) Inner Diameter, Bottom:	1.00 IN (25.40 MM)
  (E) Length:	16.50 IN (25.40 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	PLASTISOL
  Type of Endcap:	PLATED STEEL
  Center Tube:	PLATED STEEL
  Type of Media:
  Filter Area:	SQ.FT.
  Plating:	ELECTRO-GALVANIZED
  Outer Jacket:	YES - METAL
  Configuration:	SINGLE OPEN END/BH

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	6.00 LB (2.72 KG)
