All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
| Micron Rating: | 2.00 ABSOLUTE |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | N/A |
| Maximum Temperature: | 275 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 0 PSID |
| (A) Outer Diameter, Top: | 16.00 IN (406.40 MM) |
| (B) Outer Diameter, Bottom: | 16.00 IN (406.40 MM) |
| (C) Inner Diameter, Top: | 11.48 IN (291.59 MM) |
| (D) Inner Diameter, Bottom: | 0.54 IN (13.72 MM) |
| (E) Length: | 18.00 IN (13.72 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | SILICONE |
| Type of Adhesive: | EPOXY |
| Type of Endcap: | ELECTRO GALVANIZED STEEL |
| Center Tube: | ELECTRO GALVANIZED STEEL |
| Type of Media: | SPUNBOND |
| Filter Area: | 113 SQ.FT. |
| Plating: | N/A |
| Outer Jacket: | NONE |
| Configuration: | SINGLE W/BOLT HOLE |
| Number per Carton: | 1 |
