All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
| Micron Rating: | 0.00 |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | 225 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 0 PSID |
| (A) Outer Diameter, Top: | 11.40 IN (289.56 MM) |
| (B) Outer Diameter, Bottom: | 14.40 IN (365.76 MM) |
| (C) Inner Diameter, Top: | 8.00 IN (203.20 MM) |
| (D) Inner Diameter, Bottom: | 11.12 IN (282.45 MM) |
| (E) Length: | 26.00 IN (282.45 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | BUNA-N |
| Type of Adhesive: | |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | ULTRA WEB |
| Filter Area: | 189 SQ.FT. |
| Plating: | |
| Outer Jacket: | YES - METAL |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 25.00 LB (11.34 KG) |
