Filtermart™ INTAKE AIR FILTER ELEMENT

Add To Cart

FMC #22-0717

Price: TBD

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Air Filters/Intake Air

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	15.00 NOMINAL
  Beta Rating:	N/A
  Collapse Pressure Rating:	NOT RATED
  Maximum Temperature:	300 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	5.75 IN (146.05 MM)
  (B) Outer Diameter, Bottom:	5.75 IN (146.05 MM)
  (C) Inner Diameter, Top:	3.50 IN (88.90 MM)
  (D) Inner Diameter, Bottom:	3.50 IN (88.90 MM)
  (E) Length:	4.94 IN (88.90 MM)
  (F) Thread:

• Physical Specifications

  Handle:	NONE
  Seal Material:	MOLDED
  Type of Adhesive:	PLASTISOL
  Type of Endcap:	PLASTISOL
  Center Tube:	CARBON STEEL
  Type of Media:	PAPER
  Filter Area:	N/A
  Plating:
  Outer Jacket:	YES
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	5.70 LB (2.59 KG)
