All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Radial Fin Filters/Liquid or Air
| Micron Rating: | 10.00 |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 12.13 IN (308.10 MM) |
| (B) Outer Diameter, Bottom: | 12.00 IN (304.80 MM) |
| (C) Inner Diameter, Top: | 8.50 IN (215.90 MM) |
| (D) Inner Diameter, Bottom: | 0.50 IN (12.70 MM) |
| (E) Length: | 7.37 IN (12.70 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | NEOPREN |
| Type of Adhesive: | |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | STEEL |
| Type of Media: | POLYESTER |
| Filter Area: | 10.1 SQ.FT. |
| Plating: | |
| Outer Jacket: | NONE |
| Configuration: | SINGLE OPEN END W/BH |
| Number per Carton: | 1 |
| Carton Weight: | 7.00 LB (3.18 KG) |
