All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Radial Fin Filters/Liquid or Air
| Micron Rating: | 10.00 NOMINAL |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | 300 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 33.00 IN (838.20 MM) |
| (B) Outer Diameter, Bottom: | 33.00 IN (838.20 MM) |
| (C) Inner Diameter, Top: | 24.75 IN (628.65 MM) |
| (D) Inner Diameter, Bottom: | 24.75 IN (628.65 MM) |
| (E) Length: | 21.25 IN (628.65 MM) |
| (F) Thread: |
| Handle: | NONE |
| Seal Material: | FELT |
| Type of Adhesive: | |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | |
| Type of Media: | POLYESTER |
| Filter Area: | 130.7 SQ. FT. |
| Plating: | |
| Outer Jacket: | NONE |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 50.00 LB (22.68 KG) |
