All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Radial Fin Filters/Liquid or Air
| Micron Rating: | 4.00 |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 15.50 IN (393.70 MM) |
| (B) Outer Diameter, Bottom: | 15.50 IN (393.70 MM) |
| (C) Inner Diameter, Top: | 11.00 IN (279.40 MM) |
| (D) Inner Diameter, Bottom: | 11.00 IN (279.40 MM) |
| (E) Length: | 24.25 IN (279.40 MM) |
| (F) Thread: |
| Handle: | NONE |
| Seal Material: | |
| Type of Adhesive: | |
| Type of Endcap: | |
| Center Tube: | |
| Type of Media: | FELT |
| Filter Area: | SQ.IN. |
| Plating: | |
| Outer Jacket: | NONE |
| Configuration: |
| Number per Carton: | 1 |
| Carton Weight: | 35.00 LB (15.88 KG) |
