All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Separator Filters/Air/Oil
| Micron Rating: | 1.00 |
| Beta Rating: | N/A |
| Collapse Pressure Rating: | |
| Maximum Temperature: | 325 F |
| Direction of Flow: | |
| Recommended Changeout Differential Pressure: | 20 PSID |
| (A) Outer Diameter, Top: | 9.41 IN (239.01 MM) |
| (B) Outer Diameter, Bottom: | 9.63 IN (244.60 MM) |
| (C) Inner Diameter, Top: | 6.12 IN (155.45 MM) |
| (D) Inner Diameter, Bottom: | 0.69 IN (17.53 MM) |
| (E) Length: | 34.00 IN (17.53 MM) |
| (F) Thread: | N/A |
| Handle: | NONE |
| Seal Material: | NEOPRENE |
| Type of Adhesive: | N/A |
| Type of Endcap: | PLATED STEEL |
| Center Tube: | PLATED STEEL |
| Type of Media: | FIBERGLASS |
| Filter Area: | 16.95 SQ.FT. |
| Plating: | N/A |
| Outer Jacket: | YES |
| Configuration: | SINGLE OPEN END W/BH |
| Number per Carton: | 1 |
| Carton Weight: | 31.00 LB (14.06 KG) |
