All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
*12 per carton
Industrial Filters/Spin-On Filters/Paper. Microglass, Wire, Water Removal
Micron Rating: | 25.00 NOMINAL |
Beta Rating: | N/A |
Collapse Pressure Rating: | 75 PSID |
Maximum Temperature: | 225 F |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 3.72 IN (94.49 MM) |
(B) Outer Diameter, Bottom: | 3.72 IN (94.49 MM) |
(E) Length: | 7.91 IN (0.00 MM) |
(F) Thread: | 13/16-16 |
Handle: | NONE |
Seal Material: | BUNA-N |
Type of Adhesive: | PLASTISOL |
Type of Endcap: | PLATED STEEL |
Center Tube: | PLATED STEEL |
Type of Media: | PAPER |
Filter Area: | SQ.IN. |
Plating: | ELECTROTIN PLATED |
Outer Jacket: | YES - METAL |
Configuration: | SINGLE OPEN END |
Number per Carton: | 12 |
Carton Weight: | 20.30 LB (9.21 KG) |
