Filtermart™ INTAKE AIR FILTER ELEMENT

Add To Cart

FMC #28-0146

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/General Purpose Filters/Miscellaneous

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.00
  Beta Rating:
  Collapse Pressure Rating:
  Maximum Temperature:
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	8.24 IN (209.30 MM)
  (B) Outer Diameter, Bottom:	8.24 IN (209.30 MM)
  (C) Inner Diameter, Top:	7.12 IN (180.85 MM)
  (D) Inner Diameter, Bottom:	0.93 IN (23.62 MM)
  (E) Length:	22.44 IN (23.62 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:
  Type of Adhesive:
  Type of Endcap:	PLATED STEEL
  Center Tube:	STEEL
  Type of Media:	PAPER
  Filter Area:	SQ.IN.
  Plating:
  Outer Jacket:	YES
  Configuration:	SINGLE W BOLT HOLE

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	6.00 LB (2.72 KG)
