Filtermart™ PLEATED SYNTHETIC ELEMENT

Add To Cart

FMC #04-0009

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Liquid Filters/Pleated Synthetic/Polyester/Polypropylene Water Filtration

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	40.00 NOMINAL
  Beta Rating:	N/A
  Collapse Pressure Rating:
  Maximum Temperature:
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	15 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	4.25 IN (107.95 MM)
  (B) Outer Diameter, Bottom:	4.25 IN (107.95 MM)
  (C) Inner Diameter, Top:	3.13 IN (79.50 MM)
  (D) Inner Diameter, Bottom:	3.13 IN (79.50 MM)
  (E) Length:	9.50 IN (79.50 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:
  Type of Endcap:	PLATED STEEL
  Center Tube:	PLATED STEEL
  Type of Media:	SYNTHETIC
  Filter Area:	SQ.IN.
  Plating:
  Outer Jacket:	YES - METAL
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	5.00 LB (2.27 KG)
