Filtermart™ PLEATED SYNTHETIC ELEMENT

Add To Cart

FMC #04-8186

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Liquid Filters/Pleated Synthetic/Polyester/Polypropylene Water Filtration

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	1.00
  Beta Rating:	N/A
  Collapse Pressure Rating:	40 PSID
  Maximum Temperature:	140 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	25 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	7.75 IN (196.85 MM)
  (B) Outer Diameter, Bottom:	7.75 IN (196.85 MM)
  (C) Inner Diameter, Top:	3.00 IN (76.20 MM)
  (D) Inner Diameter, Bottom:	3.00 IN (76.20 MM)
  (E) Length:	30.75 IN (76.20 MM)
  (F) Thread:	N/A

• Physical Specifications

  Handle:	NONE
  Seal Material:	N/A
  Type of Adhesive:	N/A
  Type of Endcap:	URETHANE
  Center Tube:	PVC
  Type of Media:	SYNTHETIC
  Filter Area:	N/A
  Plating:	N/A
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	7.00 LB (3.18 KG)
