All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Coalescer Filters/Air/Paper-Particulate
| Micron Rating: | 0.90 NOMINAL |
| Beta Rating: | |
| Collapse Pressure Rating: | |
| Maximum Temperature: | 180 F |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 15 PSID |
| (A) Outer Diameter, Top: | 1.62 IN (41.15 MM) |
| (B) Outer Diameter, Bottom: | 1.62 IN (41.15 MM) |
| (C) Inner Diameter, Top: | 0.50 IN (12.70 MM) |
| (D) Inner Diameter, Bottom: | 0.50 IN (12.70 MM) |
| (E) Length: | 2.50 IN (12.70 MM) |
| (F) Thread: | NONE |
| Handle: | NONE |
| Seal Material: | MOLDED |
| Type of Adhesive: | URETHANE |
| Type of Endcap: | MOLDED |
| Center Tube: | |
| Type of Media: | SYNTHETIC |
| Filter Area: | SQ.IN. |
| Plating: | |
| Outer Jacket: | YES |
| Configuration: | DOUBLE OPEN END |
| Number per Carton: | 1 |
| Carton Weight: | 1.00 LB (0.45 KG) |
