Filtermart™ COMPRESSED AIR ELEMENT

Add To Cart

FMC #18-0047

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*6 per carton

Industrial Filters/Coalescer Filters/Air/Paper-Particulate

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.45 NOMINAL
  Beta Rating:
  Collapse Pressure Rating:	70 PSID
  Maximum Temperature:	150 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	15 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	2.60 IN (66.04 MM)
  (C) Inner Diameter, Top:	1.08 IN (27.43 MM)
  (E) Length:	10.00 IN (0.00 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	EPOXY
  Type of Endcap:	304 STAINLESS STEEL
  Center Tube:	304 STAINLESS STEEL
  Type of Media:	BOROSILICATE
  Filter Area:	SQ.IN.
  Plating:
  Outer Jacket:	YES
  Configuration:

• Packaging Specifications

  Number per Carton:	6
  Carton Weight:	3.00 LB (1.36 KG)
