Filtermart™ AIR COALESCER ELEMENT

Add To Cart

FMC #19-0230

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Coalescer Filters/Air/Borosilicate Glass

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.30
  Beta Rating:	N/A
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	180 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	15 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	3.39 IN (86.11 MM)
  (B) Outer Diameter, Bottom:	3.39 IN (86.11 MM)
  (C) Inner Diameter, Top:	2.03 IN (51.56 MM)
  (E) Length:	13.18 IN (0.00 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	POYLPROPYLENE
  Type of Endcap:	POLYPROPYLENE
  Center Tube:	CARBON STEEL
  Type of Media:	SYNTHETIC+CHEM
  Filter Area:	N/A
  Plating:	N/A
  Outer Jacket:	YES
  Configuration:	SINGLE OPENM END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	2.00 LB (0.91 KG)
