All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Dust Collector
Micron Rating: | 10.00 NOMINAL |
Beta Rating: | N/A |
Collapse Pressure Rating: | N/A |
Maximum Temperature: | 150 F |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 12.74 IN (323.60 MM) |
(B) Outer Diameter, Bottom: | 14.25 IN (361.95 MM) |
(C) Inner Diameter, Top: | 8.38 IN (212.85 MM) |
(E) Length: | 26.00 IN (0.00 MM) |
(F) Thread: | NONE |
Handle: | NONE |
Seal Material: | POLYISO |
Type of Adhesive: | PLASTISOL |
Type of Endcap: | PLATED STEEL |
Center Tube: | PLATED STEEL |
Type of Media: | 80/20 BLEND |
Filter Area: | 160 SQ.FT. |
Plating: | NONE |
Outer Jacket: | YES - METAL |
Configuration: | SINGLE OPEN END |
Number per Carton: | 1 |
Carton Weight: | 16.00 LB (7.26 KG) |
