Filtermart™ RADIAL FIN ELEMENT W/PREFILTER

Add To Cart

FMC #23-0040

Price: TBD

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Radial Fin Filters/Liquid or Air

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	10.00 ABSOLUTE
  Beta Rating:	N/A
  Collapse Pressure Rating:	N/A
  Maximum Temperature:	200 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	14.63 IN (371.60 MM)
  (B) Outer Diameter, Bottom:	14.63 IN (371.60 MM)
  (C) Inner Diameter, Top:	9.00 IN (228.60 MM)
  (D) Inner Diameter, Bottom:	9.00 IN (228.60 MM)
  (E) Length:	14.50 IN (228.60 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:
  Type of Adhesive:	N/A
  Type of Endcap:	PLASTISOL
  Center Tube:	STEEL
  Type of Media:	POLYESTER
  Filter Area:	49.8 SQ.FT.
  Plating:
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:	1
  Carton Weight:	19.00 LB (8.62 KG)
