Filtermart™ RADIAL FIN ELEMENT

Add To Cart

FMC #23-0114

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Radial Fin Filters/Liquid or Air

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	4.00
  Beta Rating:	N/A
  Collapse Pressure Rating:
  Maximum Temperature:	200 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (B) Outer Diameter, Bottom:	7.50 IN (190.50 MM)
  (C) Inner Diameter, Top:	4.00 IN (101.60 MM)
  (D) Inner Diameter, Bottom:	4.00 IN (101.60 MM)
  (E) Length:	5.25 IN (101.60 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	MOLDED
  Type of Adhesive:
  Type of Endcap:	PLASTISOL
  Center Tube:	EXPANDED METAL
  Type of Media:	POLYESTER
  Filter Area:	4.2 SQ.FT.
  Plating:
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:

  1
