Filtermart™ AIR/OIL SEPARATOR ELEMENT

Add To Cart

FMC #24-0788

Price: TBD

This product usually ships in 24-48 hours

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*4 per carton

Industrial Filters/Separator Filters/Air/Oil

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	0.30
  Beta Rating:	N/A
  Collapse Pressure Rating:	75 PSID
  Maximum Temperature:	275 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	20 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	4.50 IN (114.30 MM)
  (B) Outer Diameter, Bottom:	4.50 IN (114.30 MM)
  (C) Inner Diameter, Top:	3.25 IN (82.55 MM)
  (D) Inner Diameter, Bottom:	3.25 IN (82.55 MM)
  (E) Length:	72.00 IN (82.55 MM)
  (F) Thread:	NONE

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	CYANOACRYLATE
  Type of Endcap:	METAL
  Center Tube:	PERF. STEEL
  Type of Media:	FIBERGLASS
  Filter Area:	SQ.IN.
  Plating:	NONE
  Outer Jacket:	YES
  Configuration:

• Packaging Specifications

  Number per Carton:	4
  Carton Weight:	31.00 LB (14.06 KG)
