Filtermart™ AIR/OIL SEPARATOR ELEMENT

Add To Cart

FMC #24-1472

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

Industrial Filters/Separator Filters/Air/Oil

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	20.00
  Beta Rating:
  Collapse Pressure Rating:
  Maximum Temperature:
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	0 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	13.19 IN (335.03 MM)
  (B) Outer Diameter, Bottom:	13.19 IN (335.03 MM)
  (C) Inner Diameter, Top:	9.44 IN (239.78 MM)
  (D) Inner Diameter, Bottom:	9.44 IN (239.78 MM)
  (E) Length:	9.12 IN (239.78 MM)
  (F) Thread:

• Physical Specifications

  Handle:	NONE
  Seal Material:	NEOPRENE
  Type of Adhesive:	N/A
  Type of Endcap:	N/A
  Center Tube:	PLATED STEEL
  Type of Media:	FIBERGLASS
  Filter Area:
  Plating:	N/A
  Outer Jacket:	NONE
  Configuration:	DOUBLE OPEN END

• Packaging Specifications

  Number per Carton:

  1
