Filtermart™ SPIN-ON ELEMENT

Add To Cart

FMC #25-1252

Price: TBD

All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.

*12 per carton

Industrial Filters/Spin-On Filters/Paper. Microglass, Wire, Water Removal

• Product DetailsDownload Spec Sheet
• Performance Data

  Micron Rating:	144.00 ABSOLUTE
  Beta Rating:	B144 = 200
  Collapse Pressure Rating:	348 PSID
  Maximum Temperature:	225 F
  Direction of Flow:	OUTSIDE->IN
  Recommended Changeout Differential Pressure:	25 PSID

• Dimensional Specifications

  (A) Outer Diameter, Top:	3.75 IN (95.25 MM)
  (B) Outer Diameter, Bottom:	3.75 IN (95.25 MM)
  (E) Length:	5.50 IN (0.00 MM)
  (F) Thread:	1-1/2"-16

• Physical Specifications

  Handle:	NONE
  Seal Material:	BUNA-N
  Type of Adhesive:	EPOXY
  Type of Endcap:	PLATED STEEL
  Center Tube:	PLATED STEEL
  Type of Media:	WIRE MESH
  Filter Area:	SQ.IN.
  Plating:	ZINC PLATED
  Outer Jacket:	YES - METAL
  Configuration:	SINGLE OPEN/SPIN-ON

• Packaging Specifications

  Number per Carton:	12
  Carton Weight:	18.00 LB (8.16 KG)
