This product usually ships in 24-48 hours
All FilterMart replacement products are manufactured to meet or exceed the specifications of the original equipment manufacturer.
Industrial Filters/Air Filters/Intake Air
Micron Rating: | 15.00 NOMINAL |
Beta Rating: | N/A |
Collapse Pressure Rating: | NOT RATED |
Maximum Temperature: | 225 F |
Direction of Flow: | OUTSIDE->IN |
Recommended Changeout Differential Pressure: | 20 PSID |
(A) Outer Diameter, Top: | 13.84 IN (351.54 MM) |
(B) Outer Diameter, Bottom: | 13.84 IN (351.54 MM) |
(C) Inner Diameter, Top: | 9.48 IN (240.79 MM) |
(D) Inner Diameter, Bottom: | 0.53 IN (13.46 MM) |
(E) Length: | 14.00 IN (13.46 MM) |
(F) Thread: | NONE |
Handle: | NONE |
Seal Material: | BUNA-N |
Type of Adhesive: | PLASTISOL |
Type of Endcap: | PLATED STEEL |
Center Tube: | PLATED STEEL |
Type of Media: | PAPER |
Filter Area: | SQ.IN. |
Plating: | NONE |
Outer Jacket: | YES - METAL |
Configuration: | SINGLE OPEN END |
Number per Carton: | 1 |
Carton Weight: | 10.00 LB (4.54 KG) |
